Running Kafka in Kubernetes with Kraft mode and SASL authentication.

Learn how to launch an Apache Kafka with the Apache Kafka Raft (KRaft) consensus protocol and SASL/PLAIN authentication. This article is a continuation of my previous article Running Kafka in Kubernetes with KRaft mode.

PLAIN versus PLAINTEXT: Do not confuse the SASL mechanism PLAIN with the no TLS/SSL encryption option, which is called PLAINTEXT. Configuration parameters such as sasl.enabled.mechanisms or sasl.mechanism.inter.broker.protocol may be configured to use the SASL mechanism PLAIN, whereas security.inter.broker.protocol or listeners may be configured to use the no TLS/SSL encryption option, SASL_PLAINTEXT.

Prerequisites

An understanding of Apache Kafka, Kubernetes, and Minikube.

The following steps were initially taken on a MacBook Pro with 32GB memory running MacOS Ventura v13.4.

Make sure to have the following applications installed:

• Docker v23.0.5

• Minikube v1.29.0 (running K8s v1.26.1 internally)

It's possible the steps below will work with different versions of the above tools, but if you run into unexpected issues, you'll want to ensure you have identical versions. Minikube was chosen for this exercise due to its focus on local development.

Deployment Components

We need to configure brokers and clients to use SASL authentication. Refer to Kafka Broker and Controller Configurations for Confluent Platform page for detailed explanation of the configurations used here.

Broker

• Enable SASL/PLAIN mechanism in the server.properties file of every broker.

# List of enabled mechanisms, can be more than one
- name: KAFKA_SASL_ENABLED_MECHANISMS
  value: PLAIN

# Specify one of of the SASL mechanisms
- name: KAFKA_SASL_MECHANISM_INTER_BROKER_PROTOCOL
  value: PLAIN

• Tell the Kafka brokers on which ports to listen for client and interbroker SASL connections. Configure listeners, and advertised.listeners:

- command:
  ...
  export KAFKA_ADVERTISED_LISTENERS=SASL://${POD_NAME}.kafka-headless.kafka.svc.cluster.local:9092
  ...

  env: ...
  - name: KAFKA_LISTENER_SECURITY_PROTOCOL_MAP
    value: "CONTROLLER:PLAINTEXT,SASL:SASL_PLAINTEXT"
  - name: KAFKA_LISTENERS
    value: SASL://0.0.0.0:9092,CONTROLLER://0.0.0.0:29093

• Configure JAAS for the Kafka broker listener as follows:

- name: KAFKA_LISTENER_NAME_SASL_PLAIN_SASL_JAAS_CONFIG
  value: org.apache.kafka.common.security.plain.PlainLoginModule required username="admin" password="admin-secret" user_admin="admin-secret" user_kafkaclient1="kafkaclient1-secret";

Client

• Create a ConfigMap based on the sasl_client.properties file:

kubectl create configmap kafka-client --from-file sasl_client.properties -n kafka
kubectl describe configmaps -n kafka kafka-client

Output:
configmap/kafka-client created
Name:         kafka-client
Namespace:    kafka
Labels:       <none>
Annotations:  <none>

Data
====
sasl_client.properties:
----
sasl.mechanism=PLAIN
security.protocol=SASL_PLAINTEXT sasl.jaas.config=org.apache.kafka.common.security.plain.PlainLoginModule required \
username="kafkaclient1" \
password="kafkaclient1-secret";

BinaryData
====

Events:  <none>

• Mount the ConfigMap as a volume:

...
volumeMounts:
      - mountPath: /etc/kafka/secrets/
        name: kafka-client
...
volumes:
- name: kafka-client
  configMap:
    name: kafka-client

The deployment we will create will have the following components:

• Namespace: kafka This is the namespace within which all components will be scoped.

• Service Account: kafka Service accounts are used to control permissions and access to resources within the cluster.

• Headless Service: kafka-headless It exposes ports 9092 (for SASL_PLAINTEXT communication).

• StatefulSet: kafka It manages Kafka pods and ensures they have stable hostnames and storage.

The source code for this deployment can be found in this GitHub repository.

Creating the deployment

Clone the repo:

git clone https://github.com/rafaelmnatali/kafka-k8s.git
cd sasl

deploy Kafka using the following commands:

kubectl apply -f 00-namespace.yaml
kubectl apply -f 01-kafka.yaml

Verify communication across brokers

There should now be three Kafka brokers each running on separate pods within your cluster. Name resolution for the headless service and the three pods within the StatefulSet is automatically configured by Kubernetes as they are created, allowing for communication across brokers. See the related documentation for more details on this feature.

You can check the first pod's logs with the following command:

kubectl logs kafka-0

The name resolution of the three pods can take more time to work than it takes the pods to start, so you may see UnknownHostException warnings in the pod logs initially:

WARN [RaftManager nodeId=2] Error connecting to node kafka-1.kafka-headless.kafka.svc.cluster.local:29093 (id: 1 rack: null) (org.apache.kafka.clients.NetworkClient) java.net.UnknownHostException: kafka-1.kafka-headless.kafka.svc.cluster.local         ...

But eventually each pod will successfully resolve pod hostnames and end with a message stating the broker has been unfenced:

INFO [Controller 0] Unfenced broker: UnfenceBrokerRecord(id=1, epoch=176) (org.apache.kafka.controller.ClusterControlManager)

Create a topic using the SASL_PLAINTEXT endpoint

The Kafka StatefulSet should now be up and running successfully. Now we can create a topic using the SSL endpoint.

You can deploy Kafka Client using the following command:

kubectl apply -f 02-kafka-client.yaml

Check if the Pod is Running:

kubectl get pods

Output:

NAME        READY   STATUS    RESTARTS   AGE
kafka-cli   1/1     Running   0          12m

Connect to the pod kafka-cli:

kubectl exec -it kafka-cli -- bash

Create a topic named test-ssl with three partitions and a replication factor of 3.

kafka-topics --create --topic test-sasl --partitions 3 --replication-factor 3 --bootstrap-server ${BOOTSTRAP_SERVER} --command-config /etc/kafka/secrets/sasl_client.properties
Created topic test-sasl.

The environment variable BOOTSTRAP_SERVER contains the list of the brokers, therefore, we save time in typing.

List all the topics in Kafka:

kafka-topics --bootstrap-server ${BOOTSTRAP_SERVER} -list --command-config /etc/kafka/secrets/sasl_client.properties
test
test-sasl
test-ssl
test-test

Summary and next steps

This tutorial showed you how to get Kafka running in KRaft mode on a Kubernetes cluster with SASL authentication. This is another step to secure communication between clients and brokers in addition to the SSL encryption discussed in this article. I invite you to keep studying and investigating how to improve security in your environment.
